ASROCK – RADRX675XT12ASRPGD

Asrock RX6750 XT Phantom Gaming D OC, 12GB DDR6, PCIe4, HDMI, 3 DP, 2623MHz Clock, Crossfire, RGB, Overclocked

Specification

• Chipset Manufacturer: AMD
• Interface: PCI Express 4.0
• Graphics Chipset: AMD RX 6650 XT
• Memory Size: 12GB
• Memory Type: GDDR6
• Memory Interface: 192-bit
• Core Clock:
  • Boost Clock: Up to 2623 MHz
  • Game Clock: Up to 2554 MHz
  • Base Clock: 2623 MHz
• Memory Clock: 18 Gbps
• CUDA Cores / Stream Processors: 2560 Stream Processors
• Outputs:
  • 1 x HDMI 2.1 VRR
  • 3 x DisplayPort 1.4 with DSC
• HDCP Support: Yes
• Resolution: Digital Max Resolution: 7680×4320
• DirectX Support: DirectX 12 Ultimate
• Max Display Support: 4
• Cooling:
  • Phantom Gaming 3X System
  • Striped Axial Fans
  • Air Deflecting Fin
  • Ultra-fit Heatpipe
  • Nickel Plated Copper Base
  • High Density Metal Welding
  • Nano Thermal Paste
  • Premium Thermal Pad
  • 0dB Silent Cooling
• PSU Requirements: 700W or greater recommended
• Connectors Required: 2 x 8-pin PCIe power
• Additional Features: See Overview
• Dimensions: 305 x 131 x 55 mm
• Slot Size: 2.75 Slot
• Accessories: 1 x Quick Installation Guide
• Package Type: Retail
• Package Weight: 1.8500 kg
• Warranty: 2 Year Replacement Warranty

AMD Radeon RX 6750 XT Phantom Gaming D 12GB OC – RX6750XT PGD 12GO

• Boost Clock: Up to 2623 MHz / 18 Gbps
• Game Clock: Up to 2554 MHz / 18 Gbps
• Base Clock: 2623 MHz / 18 Gbps
• Graphics Chipset: 7nm AMD Radeon™ RX 6750 XT
• Memory Size: 12GB
• Memory Interface: 192-bit GDDR6
• Architecture: AMD RDNA™ 2
• DirectX Support: DirectX 12 Ultimate
• PCI Express Support: PCI® Express 4.0
• Power Connectors: 2 x 8-pin
• Outputs:
  • 3 x DisplayPort™ 1.4 with DSC
  • 1 x HDMI™ 2.1 VRR
• Cooling:
  • Phantom Gaming 3X Cooling System
  • Striped Axial Fan
  • Reinforced Metal Frame
  • Stylish Metal Backplate
  • 0dB Silent Cooling
• Additional Features:
  • Polychrome SYNC
  • Super Alloy Graphics Card
  • Air Deflecting Fin
  • Nickel-plated Copper Base
  • High-density Metal Welding
  • Nano Thermal Paste
  • Premium Thermal Pad
  • Precise Screw Torque

Overview

OC Edition – Great Performance

Delivers performance surpassing reference cards with solid hardware design.

Cooling

• Phantom Gaming 3X Cooling System: Balances thermal efficiency and silence.
• Striped Axial Fan: Enhanced airflow with optimized cooling.
• Air Deflecting Fin: Guides airflow for better cooling efficiency.
• Ultra-fit Heatpipe: Maximizes contact and heat dissipation.
• Nickel-plated Copper Base: Improves thermal transfer to the GPU.
• High-density Metal Welding: Enhances heat dissipation.
• Nano Thermal Paste: Maximizes heat transfer and thermal efficiency.
• Premium Thermal Pad: Improves heat dissipation to the heatsink.
• Precise Screw Torque: Optimizes cooler mounting pressure and improves thermal efficiency.
• 0dB Silent Cooling: Fans spin for cooling and stop for silence.

Engineering

• Polychrome SYNC: Customizable ARGB lighting effects, synchronized with compatible ASRock motherboards.
• LED On/Off Switch: Control ARGB LEDs and connected devices.
• ARGB Pin-header: Connect additional ARGB strips for richer lighting effects.
• Reinforced Metal Frame: Prevents PCB bending.
• Stylish Metal Backplate: Enhances visual appeal and cooling.

Super Alloy Graphics Card

• Dr. MOS: Integrated power stage solution delivering higher current for superior performance.
• Premium 60A Power Choke: Enhanced Vcore voltage.
• 2oz Copper PCB: Improved temperature and energy efficiency.
• Matte Black PCB: Aesthetic color scheme.
• High Density Glass Fabric PCB: Protects against electrical shorts from humidity.

ASRock Tweak 2.0

• Pro and Easy-to-Use Tuning Utility: Offers smart fan speed control and performance tweaking.

Resolution Support

• 8K Resolution: Supports 4K and 8K video output for a superior visual experience.

PCI Express 4.0 Support

• Bandwidth: Twice the bandwidth compared to PCI Express 3.0, preparing for next-generation gaming.
