ASUS – NVRTX4070S12ASDUALEVOOC

Asus DUAL RTX4070 SUPER EVO OC, PCIe4, 12GB DDR6X, HDMI, 3 DP, 2550MHz Clock, Overclocked

Description

The ASUS Dual GeForce RTX 4070 SUPER EVO OC Edition delivers powerful graphics performance with its advanced cooling and compact design, perfect for gamers seeking high performance in smaller builds.

Specification:

• Chipset Manufacturer: Nvidia
• Interface: PCI Express 4.0
• Graphics Chipset: Nvidia RTX 4070 SUPER
• Memory Size: 12GB
• Memory Type: GDDR6X
• Memory Interface: 192-bit
• Core Clock:
  • OC Mode: 2550 MHz (Boost Clock)
  • Default Mode: 2520 MHz (Boost Clock)
• Memory Clock: 21 Gbps
• CUDA Cores / Stream Processors: 7168 CUDA Cores
• Outputs:
  • 1 x HDMI 2.1a
  • 3 x DisplayPort 1.4a
• HDCP Support: Yes
• Resolution: 7680 x 4320
• Multi-GPU Support: None
• Max Display Support: 4
• Cooling:
  • Dual Fan
  • Axial-tech Fans
  • 0dB Technology
  • Dual Ball Fan Bearings
• PSU Requirements: 750W or greater recommended
• Connectors Required: 1 x 16-pin power
• Software: ASUS GPU Tweak III, GeForce Game Ready Driver, Studio Driver
• Additional Features: See Overview
• Dimensions: 227.2 x 123.24 x 49.6 mm
• Slot Size: 2.5 Slot
• Accessories:
  • 1 x Speedsetup Manual
  • 1 x Thank You Card
  • 1 x Adapter Cable (1 to 2)
• Package Type: Retail
• Package Weight: 1.400 kg
• Warranty: 3 Years

ASUS Dual GeForce RTX 4070 SUPER EVO OC Edition

Description

The ASUS Dual GeForce RTX 4070 SUPER EVO OC Edition combines powerful Axial-tech fans and a 2.5-slot design for broad compatibility and superior cooling. Powered by NVIDIA DLSS3, the ultra-efficient Ada Lovelace architecture, and full ray tracing, this graphics card offers remarkable performance and efficiency.

Key Features:

• NVIDIA DLSS3 and Ada Lovelace Architecture: Enhances performance with AI-driven technologies.
• 4th Generation Tensor Cores: Up to 4x performance improvement with DLSS 3 compared to brute-force rendering.
• 3rd Generation RT Cores: Provides up to 2x ray tracing performance.
• Axial-tech Fan Design: Features a smaller fan hub for longer blades and a barrier ring that increases downward air pressure.
• 2.5-Slot Design: Maximizes compatibility and cooling efficiency for superior performance in compact builds.
• 0dB Technology: Enables silent operation during light gaming sessions.
• Dual Ball Fan Bearings: Offer durability, lasting up to twice as long as sleeve bearing designs.

Cooling:

• Axial-tech Fan Design: Includes two fans with a smaller hub for improved airflow.
• 0dB Technology: Stops the fans when GPU temperatures are low for silent operation.
• Dual Ball Fan Bearings: Provide enhanced durability and longer lifespan.
• 2.5-Slot Design: Enhances thermal performance with a well-designed shroud and heatsink layout.
• Dual BIOS: Choose between Performance mode for lower core temperatures or Quiet mode for reduced noise.

Engineering:

• Auto-Extreme Technology: Automates soldering in a single pass, reducing thermal strain and environmental impact.
• Protective Backplate: Reinforces the PCB, adds structural rigidity, and helps with heat dissipation.
• Stainless Steel Bracket: Provides additional strength and corrosion resistance.

Software:

• GPU TWEAK III: Advanced utility for tuning GPU core clocks, memory frequency, voltage settings, and fan control.
• QuantumCloud: Allows users to earn money by sharing their graphics card’s computing power, with privacy protection and multiple payment options.

Experience:

• 144-hour Validation Program: Tests the card for compatibility with the latest games to ensure high performance.
